Clean Room HEPA Air Filter Wooden Frame With Paper Foil Separator 610x610x150mm

Clean Room HEPA Air Filter Wooden Frame With Paper Foil Separator 610x610x150mm
Clean Room HEPA Air Filter Wooden Frame With Paper Foil Separator 610x610x150mm

Hình ảnh lớn :  Clean Room HEPA Air Filter Wooden Frame With Paper Foil Separator 610x610x150mm

Thông tin chi tiết sản phẩm:
Place of Origin: Guangdong, China (Mainland)
Hàng hiệu: Zhisheng
Chứng nhận: ISO 9001, Rohs
Model Number: ZS-YGX-6101
Thanh toán:
Minimum Order Quantity: 50 pieces
Packaging Details: plywood case
Delivery Time: about 15 days upon receipt of deposit
Supply Ability: 500 pieces per month

Clean Room HEPA Air Filter Wooden Frame With Paper Foil Separator 610x610x150mm

Sự miêu tả
External frame: Aluminum Frame Separator: paper foil
Size: 610x610x150mm Max temperature: 80℃
Max Humidity: 80% Sealant: polyurethane rubber
Điểm nổi bật:

air purifier filters

,

custom air filters



High Efficiency Deep Pleated Separator Air Purifier h13 Hepa Filter



Description:



High capacity HEPA filter are mainly used to filtrate the suspended particles in the air with the diameter of 0.3um and below and used for the terminal filtration of all kinds of filtration system.



Advantages:

  • High efficiency for H13,h14.
  • Large dust capacity,because the filter media adopts the ultrathin glass fiber, the hot melt glue spacing each pleats in regular so that achieve high dust volume.
  • Aluminum frame of High Quality Deep Pleat Air Purifier H13 HEPA Filter Factory can anticorrosion for long time.
  • Sealant around the media prevent the air filter is without any air leaking.
  • HEPA filter with metal screens, preventing damage to the filter media
  • High Quality Deep Pleat Air Purifier H13 HEPA Filter Factory comes with relative light weight for easy to install
  • Deep-pleat H10H12H13H14 HEPA Air Filters



Material and operating conditions:



External frame aluminum / GI/ wooden
Sealant polyurethane rubber
Separator paper or aluminum foil
Filter media fiberglass, HV fiberglass or PP
Maximum operating temperature 80°C
Maximum operating humidity 80%
HEPA filter Efficiency 95-99.995%





Features:



1: The HEPA with aluminum separator is the finally filtration in clean room that use for filter the particles more than 0.3um, and in high airflow environment.

2: The media is used of micro glass fiber, the paper clapboard or the aluminum foil spacer in regular so that the refresh air pass through the media very easy. make the best of area used and increase the intensity of the pleats

3: The paper / aluminum foil media in 180 degree fold that compost of the wedge layer so that prevented the media damage.

4: The sealant around the media so that the air filter without any air leaking,

the frame can be wooden, aluminum,galvanized or stainless steel.

5: Laser to scan the each air filter one by one,

6: The HEPA air filter efficiency range: H10, H11, H12 H13, H14,

95%-99.99995%@0.3um (EN1822).

7: Each air filter with test report accompany



Size and Specification:



Model Outside dimensions
(mm)
Rated air flow(m/h) Initial resistance (Pa) Efficiency
ZS-YGX-484 484x484x220 1000 ≤120(PP)
≤220(fiberglass)
≤120(HV (fiberglass)
95-99.995%
(F9-H14)
ZS-YGX-295 295x595x292 1600
ZS-YGX-595 595x595x292 3200
ZS-YGX-6101 610x610x150 1000
ZS-YGX-6102 610x610x292 3400
ZS-YGX-305 305x610x292 1700
ZS-YGX-630 630x630x220 1500
ZS-YGX-1220 1220x610x150 2000




Pictures of HEPA filter





Clean Room HEPA Air Filter Wooden Frame With Paper Foil Separator 610x610x150mm 0







Payment Term:



30% prepayment by T/T at order, the balance of payment before shipment.



Delivery time:



Production period:15-30days

• Shipping notice or insurance for you after the goods is shipped.



After sales service:



We respect your feed back after receive the goods.

• We provide 1 year warranty after goods arrive.

• We care of your complain within 48hours.
